This article consists of:
Description
Easily identify anomalies such as hotspots, contamination, corrosion or glass breakage
You use a combination of drone technology, thermography and visual images to reliably identify defects from the air. Depending on the type of defect, the anomalies can be recognised as hot spots, thermal image patterns or objects in the visual image, for example. With our solution, you have all the options at your fingertips.
Market-leading inspection drone
The right "tool" is essential for a reliable inspection of PV systems. The DJI Mavic 3T drone boasts an integrated thermographic camera and a view camera. At 640 x 512 pixels, the infrared resolution is even higher than that of many hand-held cameras. Handling is very simple and can usually be learnt by anyone within 1-2 hours.
Thermography professional training
In our high-quality online on-demand thermography training, we impart sound expert knowledge from practical experience. From professionals for professionals. Optionally also available as on-site training at your premises or at an Airclip location. Dates on request.
Thermography service and support
Our experienced thermography experts, with many years of professional experience, will help you with even the most complex issues.
Optical inspection of PV systems: fast, safe and cost-effective
In addition to thermography, the M3T camera offers an RGB mode that enables 4K recordings without any loss of quality. Thanks to the 56x hybrid zoom, even the smallest damage to modules, connectors or cables can be detected from a great distance. This technology enables a comprehensive inspection of the PV system without the use of expensive aids such as scaffolding or cherry pickers, which reduces time, costs and safety risks.
Optional PV multimeter for professionals
We offer the Benning SUN 2 photovoltaic multimeter as an optional package component so that you can conveniently measure the irradiation power on site, for example. It is ideal for planning, commissioning and periodic testing of grid-connected PV systems in accordance with VDE 0126-23 and for testing solar thermal systems.
Ready-to-fly provision
We take care of the complex setup and optimisation of your drone. All components are harmonised so that you can get started immediately. Including flight test before delivery.
Class A2 drone licence
An A2 drone licence is required to operate the included drone. Our package already includes the appropriate on-site training for legally compliant use. This is also optionally available as A2 online training. Do you already have an A2 drone driving licence? No problem: we customise our offer to your individual needs.
Customisable on request
Do you already have a drone driving licence or comprehensive knowledge of thermography or do you already have a drone? We will provide you with a customised offer tailored to your needs - contact us today.
Customer reviews
Wir nutzen den Airclip Service um komplexe Dächer in PVSol schnell und genau planen zu können.
So sinkt der Zeitaufwand für unsere Dachplaner erheblich und die Kunden freuen sich über ein cooles
3D Modell vom Haus. Am Ende passt alles dann genau so aufs Dach wie geplant!
Christoph Glaubke von Enerix, 26655 Westerstede
Die zeitnahe Bearbeitung der 3D-Daten funktioniert einwandfrei. Das Fliegen ebenfalls. Auch individuelle Wünsche werden schnell eingearbeitet. Dazu gibt es viel hilfreiches Online-Material und persönlichen Support. Wir sind sehr zufrieden!
Solarwatt GmbH, 01109 Dresden
Unser Drohnen-Team kann mit den Drohnen und der Software von Airclip alle Auffälligkeiten sehen
und Dächer vermessen!
Tony Friedrich von Energiekonzepte Deutschland GmbH, 04347 Leipzig
Wir erstellen nur noch Ausführungspläne mit der Drohne da wir hier genauer sind also ohne Drohne
zuvor. Auch die Zeitersparnis gegenüber der Vermessung von Hand ist riesig. Da Wir keine
Dächer mehr besteigen müssen ist auch der Punkt Sicherheit sehr wichtig. Ein Vermessen ohne
Absturzsicherung ist in der Praxis nicht mehr zu vertreten. Die Technik ist sehr zuverlässig auch
bei schwierigen Verhältnissen ist diese Dank einfacher Bedingung immer sicher zu beherrschen. Wir
haben bisher über 200 Objekte befolgen und sind sehr zufrieden. Bei der Menge an Anlagen die wir
umsetzen ist das innerhalb weniger Monate bezahlt. Je nach Umfang der Anlage liegt die Zeitersparnis pro
Objekt zwischen 30 und 90 Minuten. Da die Daten digital und in hoher Qualität vorliegen ist die
Weiterverarbeitung auch sehr schnell und gut.
Kenny Breuer von Staudt GmbH, 76698 Ubstadt-Weiher
Wir arbeiten seit einem halben Jahr mit der Firma Airclip zusammen, die für uns 3D-Modelle für
unsere Kundenobjekte liefert. Der Cloud-Service für den Datenaustausch ist unkompliziert und
lässt sich reibungslos in unsere eigenen Unternehmensprozesse integrieren. Die gelieferten
3D-Modelle sind stets zeitnah verfügbar, von hoher Qualität und hieven unsere
Photovoltaik-Anlagenplanungen auf ein neues Level. Die Zusammenarbeit mit dem Airclip-Team war stets
kooperativ und professionell.
Manuel Madiener von Solmotion Project GmbH, 88214 Ravensburg
Airclip ist unser Partner für Dachaufmaße, Inspektionen und rechtliche Themen rund um
unser Drohnen-Team. Wir sind sehr zufrieden mit den empfohlenen und gelieferten Drohnen und Software-Lösungen!
energiehaus blechinger GmbH, 38448 Wolfsburg
Dank der smarten Lösung von airclip können wir unseren Kunden maßgeschneiderte Angebote
für PV-Anlagen erstellen.
Tobias Schwarz von Elektrotechnik Karl Schwarz GmbH, 89362 Offingen
Unsere Zusammenarbeit mit der Firma Airclip ist sehr kooperativ und wir sind froh, einen innovativen
Partner an unserer Seite zu haben. Der Mehrwert für unsere Kunden/Projekte durch den Drohneneinsatz
ist deutlich spürbar.
Andreas Alkens von Ailutec, 26826 Weener
Einfaches Dachaufmaß. Schnelle, unkomplizierte Erstellung der Obj-Datei.
Knut Schaeffter von Edling & Schaeffter GmbH, 65428 Rüsselsheim
Immer schnell wenn Hilfe benötigt wird, sehr freundlich und sehr kompetent. Alles funktioniert so wie
versprochen.
Sven Dönnewald von ewenso Betriebs GmbH, 33449 Langenberg
Persönlicher und schneller Service. Das Unternehmen ist sehr Kundenorientiert aufgestellt. Bin sehr
begeistert.
Julian Wolf von Energiesysteme und Dienstleistungen Julian Wolf, 79802 Dettighofen
FAQ
Why is a thermographic inspection of photovoltaic systems important?
Thermography is an indispensable tool for quickly and effectively checking the condition of photovoltaic systems. This technology is particularly helpful when it comes to unexplained performance losses. Thermal imaging technology can be used to quickly identify defective modules and determine the exact cause of problems. Defects in the PV modules increase the electrical resistance locally, which leads to visible heat development and is easily recognisable on a thermal image.
What does the drone solution for inspecting PV systems include?
Our complete solution includes a powerful drone with an integrated thermographic camera, training in safe drone handling and thermographic analysis as well as comprehensive technical support.
Which drone is used for the inspection?
We offer a high-quality drone from the manufacturer DJI that has been specially developed for inspection applications. It is equipped with a high-resolution thermographic camera that enables precise temperature measurements and thus quickly identifies possible defects in solar modules.
How does thermographic inspection of PV systems work?
Thermography uses infrared radiation to measure temperature differences on the PV modules. Damaged modules heat up more and become visible through the thermographic camera as so-called hotspots, indicating possible defects.
Do I need any special prior knowledge to operate the drone?
No, our solution is also suitable for beginners. The training included in the package teaches you everything you need to know about controlling the drone, using the thermography technology and analysing the results.
How long does the training take?
Training for the A2 drone licence, including flight training and examination, takes 2 days at one of our locations in Germany. The prerequisite for this is that you already have an A1/A3 drone licence, which you can easily obtain online from the Federal Aviation Office within 30-60 minutes (costs <50 EUR). The user training for PV thermography is online and on-demand. You should plan around 1/2 to 1 day for this, including application examples.
Can I also use the drone for other inspection purposes?
Yes, the drone is versatile and can also be used for other inspection and detection tasks. Typical examples are thermography on buildings, fawn rescue or the inspection of hard-to-reach systems with a visual and infrared camera.
How often should a PV system be inspected?
It is recommended to inspect PV systems at least once a year in order to recognise potential damage at an early stage and maintain the efficiency of the modules.
What are the advantages of thermographic inspections by drone compared to conventional methods?
Thermographic inspections by drone are faster, more efficient and safer than conventional manual inspections. No scaffolding or climbing equipment is required and even areas that are difficult to access can be reached effortlessly. Thermography also delivers precise and reliable results.
How do I get the inspection results?
The drone records both visual and thermographic data, which can then be analysed in detail. With our training, you can use this to create a complete inspection report including high-resolution images and temperature data.
What are the technical specifications of the infrared camera
- Frame rate: 30 Hz
- Noise equivalent temperature difference (NETD): ≤50 mK@F1.0>
- Infrared temperature measurement accuracy: +- 2°C or +-2% (when using a larger value)
- Image format: JPEG (8 bit), R-JPEG (16 bit)
Two 12 MP view cameras are also installed.
What support does the technical and thermographic support offer?
Our support team will help you set up and configure the drone and analyse the thermographic data.
